| Description | |
|---|---|
| Designed for three-phase ~400V, 50Hz frequency electricity energy distribution and protection against overloads or short circuits, as well as for the installation of energy meters. The module of the cable part is adapted to install fuse switch disconnectors of various manufacturers. The sealed module of the metering part is suitable for installation of different types of direct connection electricity metering devices. Suitable for indoor and outdoor use. Self-ventilated, moisture-proof and dust-proof. Mounting methods: on the foundation, on the wall or support. Standard color - RAL 7032. Other colors are available according to project needs. | |
| Technical Parameters | |
| Nominal voltage Un | 400/230V |
| Insulation voltage Ui | 400V |
| Nominal current In | ≤ 400A |
| Short-time withstand current lcw | ≤ 10kA |
| Nominal frequency f | 50 Hz |
| Ambient temperature | -35...+35°C |
| Degree of protection | IP44 |
| Mechanical impact | IK08 |
| Door opening angle | 120° |
| Construction Material & Coating | |
| Frame, doors | Galvanized sheet steel DXS1+AZ150, t=1.5mm, Powder painting: RAL 7032, ≥ 80µm |
| Base | Sheet steel S235, t=2.5mm, Hot-dip zinc coating, ≥ 70µm |
| Dimensions (Height/Width/Depth in mm) | |
| EKAS-2/1h* | 1300 / 600 / 300 |
| EKAS-3/1h* | 1300 / 800 / 300 |
| EKAS-4/1h* | 1300 / 1000 / 300 |
| EKAS-6/2v** | 1300 / 1200 / 300 |
| EKAS-2/4v** | 1750 / 520 / 300 |
| EKAS-3/4v** | 1750 / 730 / 300 |
| EKAS-2/2h* | 1320 / 520 / 300 |
| EKAS-3/3h* | 1320 / 730 / 300 |
| EKAS-4/2h* | 1750 / 520 / 300 |
| EKAS-5/9v** | 1750 / 1000 / 300 |
| EKAS-6/3h* | 1750 / 730 / 300 |
| EKAS-10/4h* | 1750 / 1000 / 300 |
| The height of the base | 1000 |
| Standards | |
| IEC/EN 61439-1, IEC/EN 61439-5, IEC/EN 60529, IEC/EN 62262, LST EN 10346, LST ISO 1461 | |
